hook type commutator for household appliances from China manufacturer

hook type commutator for household appliances

Payment Terms:	T/T,L/C,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: Riser type\ tang type

Production Capacity: 100 million/year

Delivery Date: 30 working days

Insulation between bars: Mica

Bushing: Steel,brass and spiral

Means of Transport: Ocean,Land,Air

Packing: carton

Commutator bars: Sliver-bearing copper

Moulding compound: Phenolic

Reinforced rings: Steel or glass epoxy

NIDE is specialized in researching,developing and manufacturing slot,hook and flat types of commutator for DC motors and universal motors.

Commutator for household appliances

Part No.	Bar No.	O.D(D)	I.D(d)	Bar Length(L1)	Total Length(L)	Hook Height(D1)	L2	a	hook widthXthick	effective lenth
NDP970	10	15	6.35	8	10	18.2	2.5	16°	1.6X0.7	7
NDP015	12	16.6	6.35	8.5	11.2	20.6	2.4	30°	1.1X0.9	8.8
NDP016	12	18.9	6.35	9.5	13.5	23	3.2	15°	1.5X0.9	10
NDP017	12	18.9	7.14	9.5	11.7	22.5	2.8	15°	1.5X0.9	8.6
NDP940	16	32.13	12.67	15.43	20.24	40.23	6.16	11°±5°	1.91X1.8	13
NDCS707	24	18.9	6.35	11	12.5	22.5	2.7	24°	1X0.6	9
NDC619C	24	21.5	8	9.6	11.4	25	2.3	16°	1X0.8	8.8
NDC631A	24	21.5	8	10.6	12	25	2.2	(19°)	1.1X0.8	8.8
NDD838	24	22	8	15.7	19	27.3	3.2	30°	0.9X1.2	13.7
NDC215	24	22.5	8	13.2	18	27.8	3.2	(22°)	1.2X1	10.8
NDC087	24	25.5	8	14.8	17.2	30.2	3	20°	1.3X0.9	12.7
NDDS987	22	21.5	8.14	14.1	17	25	2.5	15°	1X0.9	11.7
NDC129	22	23.4	8.09	15.5	20.5	28	2.7	29°	1.1X0.9	15.3
NDD052	22	23.4	8.14	15.5	20.5	28	2.7	30°	1.1X0.9	13.8
NDD059	22	23.4	8.14	14.5	20	28	2.7	30	1.1X0.9	12.8
NDD059	22	23.4	8.14	14.5	20	28	2.7	30	1.1X0.9	12.8
NDD052B	22	23.4	8.15	15.8	17.5	28	2.7	30°	1.1X0.9	13.8
NDD052L	22	23.4	8.15	16.5	17.5	28	3.7	(30°)	1.1X0.9	14.7
NDDS052B	22	23.4	9.6	15.5	20.5	28	2.7	(30°)	1.1X0.9	13.8
NDDS052C	22	23.4	9.6	18	22.5	28	2.7	30°	1.1X0.9	15.8
NDDS945B	22	23.4	9.6	16.5	20	28	2.7	20°	1.2X1	14.8
NDD867	22	25.43	9.888	18.01	19.2	30.58	3.4	(17°)	1.52X0.99	15.4
NDC845S	22	28.5	9.898	17.3	20	34	3.5	28°	1.4X1.1	15
NDD936	22	28.58	9.899	16.76	26.75	33.78	3.43	(22°)	1.55X1.14	14.88
NDD844B	22	32.38	9.9	17.91	20.22	37.84	3.81	21°	1.6X1.14	14.8
NDD877	22	32.38	9.9	20.86	23.17	37.85	3.72	(22°)	1.6X1.14	17.84
NDD425	22	32.38	9.911	17.91	20.22	37.84	3.68	16°	1.6X1.14	15.54
NDC168	24	18.7	7.08	11	14.1	22	2.3	7°	0.8X0.7	9.6
NDD898A	24	18.7	7.08	11	14.1	22	2.3	(7°)	0.8X0.7	9.6
NDC130	24	21.5	8.14	13.4	17	26	3	20°	1.2X0.8	10.9
NDC930F	24	24.68	8.03	16.8	19.2	29.43	3.1	20°	1.14X1.02	14.5
NDC930	24	24.68	8.1	16.8	19.2	29.83	3.1	20°	1.14X1.02	14.5
NDC930B	24	24.68	9.9	16.8	19.2	29.43	3.1	20°	1.14X1.02	14.5
NDD862A	24	25.5	8	16.5	20.5	30.8	3.1	(17.5°)	1.25X1.1	16.4
NDC225	28	24.5	9.48	12.9	14.13	28.45	2.73	(17°)	1.27X0.8	11
NDD866	28	34.01	9.922	20.78	26.28	39.49	3.43	(23°)	1.44X1.14	19.63
NDC224	32	34.96	8.7	15.7	19.3	39.75	3.01	(19°)	1.5x0.98	13.46
NDC092Z	36	40.47	15.02	20.5	24.5	35	3.4	(33.6°)	1.2X1.2	18
NDC241A	36	40.47	18.8	19.5	24.5	46.2	3.5	(30°)	1.15X1.1	17
NDC092K	36	40.5	15.075	21.7	28	47.5	5	30°	1.2X1.1	18
NDC092X	36	40.5	15.1	21.9	28	47.4	5	30°+3°	1.2X1.2
NDC092B	36	40.5	15.1	24.4	28	47.4	5	30°	1.2X1.1	18
NDC299B	36	40.5	15.1	21.9	28	47.4	5	(29°)	1.2X1.2	19.9
NDC243	36	40.5	15.1	22	28	47.3	4.1	(31°)	1.2X1.2	18.4
NDC243B	36	40.5	15.1	22	28	47.3	4.1	(31°)	1.2X1.2	18.4
NDC243A	36	40.5	17.67	22	28	47.3	4.1	(31°)	1.2X1.2	18.4
NDC243C	36	40.5	17.67	22	28	47.3	4.1	(31°)	1.2X1.2	18.4
NDCS241B	36	40.5	18.8	19.5	24.5	46.2	3.5	(33°)	1.15X1.1	17
